Multilayer PCB Board with 0.15mm Back Drill for Manufacturing

Product Description:

With a minimum PAD of 0.14mm for Inner Layer, our Multilayer PCB Board is designed to provide maximum performance and efficiency for your Network Server Multilayer needs. The Misalignment of layers is only 0.1mm, ensuring the highest level of accuracy and precision in your designs.

The Aspect Ratio of our Multilayer PCB Board is 20:1, providing a flexible and versatile solution for your complex electronic designs. Our Back drill of 0.15mm ensures that you can achieve the highest levels of precision and accuracy in your Multilayer Circuit Board designs.

Our Multilayer PCB Board is also designed with Impedance Control of ±5%, ensuring that your designs are optimized for performance and efficiency. With our FR4 Multilayer PCB, you can be confident that your Network Server Multilayer needs will be met with the highest level of quality and reliability.

Features:

• Product Name: FR4 Multilayer PCB
• Aspect Ratio: 20:1
• Surface Treatment:
  • HASL
  • ENIG
  • Immersion Silver
  • OSP
  • Immersion TIN
  • ENIG+OSP
  • HASL+Goldfinger
  • Electroplated Gold
  • Electroplated Silver
• Impedance Control: ±5%
• Min. Core Thickness: 0.03mm
• Layer: 2-48L

Applications:

Kingtech Multilayer PCB Board is a high-quality FR4 Multilayer PCB product that is designed and manufactured in China. The product comes with an excellent Impedance Control of ±5%, Min. Line Width/Space of 0.05/0.05mm, and Back drill of 0.15mm. The maximum board thickness of the product is 6.0mm, and the maximum board size is 1000*600mm.

The Multilayer PCB Board is suitable for various application occasions and scenarios such as Network Server Multilayer, 10 Layer PCB, and other electronic devices. The product is widely used in the telecommunication, automotive, medical, military, and aerospace industries.

The Network Server Multilayer is one of the primary application occasions for Kingtech Multilayer PCB Board. The product is designed to provide high-speed data transmission, reduce electromagnetic interference, and increase the stability and reliability of the server system. The Multilayer PCB Board is capable of handling complex circuit designs, providing more significant routing flexibility, and reducing the overall size of the server system.

Kingtech Multilayer PCB Board is also an excellent choice for 10 Layer PCB applications. The product is designed to provide high-density interconnects, reduce signal noise, and improve signal integrity. The Multilayer PCB Board is capable of handling high-frequency signals, providing more excellent power distribution, and reducing the overall system cost.

In summary, Kingtech Multilayer PCB Board is an excellent choice for various application occasions and scenarios such as Network Server Multilayer, 10 Layer PCB, and other electronic devices. The product is designed to provide high-quality performance, reliability, and stability.

Customization:

Kingtech offers Product Customization Services for FR4 Multilayer PCBs with 10 Layer PCBs, originating from China. Our Max. Board size is 1000*600mm, and we use Min. Vias Hole Size of 0.15mm and Min. Line Width/Space of 0.05/0.05mm. We ensure Impedance Control of ±5% and our Min. Core Thickness is 0.03mm.
